에이 hydraulic sawdust briquette machine is a high-pressure biomass press designed to convert dry sawdust into dense fuel briquettes. It uses a hydraulic cylinder to apply static pressure instead of rotating screws. The SL-60 model processes approximately 80 kg of sawdust per hour, producing 1,200–1,500 briquettes hourly depending on mold size.

The machine handles hardwood sawdust, softwood sawdust, bamboo powder, and other biomass wastes with moisture content around 20% . No binder is required. Under 60–70 MPa hydraulic pressure, loose particles interlock into solid 60 mm or 70 mm cylindrical briquettes. These briquettes burn directly in stoves and boilers, or serve as feedstock for carbonization into charcoal.

This biomass sawdust briquette machine suits furniture factories, sawmills, and biomass fuel producers who need a compact, low-noise, easy-to-operate briquetting solution.

기술 사양

Raw Materials and Applications

This sawdust fuel briquette machine processes various dry biomass wastes:

• Hardwood sawdust (oak, birch, beech)
• Softwood sawdust (pine, spruce, poplar)
• Bamboo powder
• Rice husk (finely ground)
• Peanut shell powder
• Mixed wood waste from furniture factories

The finished briquettes are ideal for:

• Home heating stoves
• Industrial boiler fuel
• Barbecue fuel (after carbonization)
• Activated carbon feedstock
• Biomass power plant co-firing

Hydraulic vs Screw Extrusion Sawdust Briquette Machines

Buyers often ask which technology is better. Both produce sawdust briquettes, but they work differently and serve different production needs.

• When to choose hydraulic: You process moderate volumes (under 2 tons/day), want simple operation, or work in noise-sensitive environments. The sawdust fuel briquette machine with hydraulic drive requires less maintenance and no pre-heating.

• When to choose screw: You need continuous high-volume output (over 200 kg/h) and produce for industrial boiler markets that accept extruded rod shapes. Screw sawdust briquette making machines offer higher throughput but consume more power and require frequent screw replacement.

For most small to medium biomass operations, the hydraulic model offers better return on investment and simpler daily operation.

Key Features of the Hydraulic Sawdust Briquette Machine

• High-pressure hydraulic system. The main cylinder generates 60–70 MPa of pressure. This compresses sawdust into dense briquettes with high calorific value and low ash.
• Dual mold options. The standard 60-type machine accepts two mold diameters: 60 mm and 70 mm. Change molds in 30 minutes to match different burner requirements.
• Energy-efficient drive. Total power is only 13.25 kW (11 kW main motor + 1.5 kW hydraulic pump + 0.75 kW feeder). This is 30–50% less than comparable screw machines.
• No heating required. Unlike screw extruders, this biomass sawdust briquette machine needs no electric heating ring. It presses at room temperature, saving energy and eliminating burn risks.
• Compact footprint. Dimensions are 1,650 × 1,550 × 1,500 mm. Weight is 800 kg. The machine fits in a standard workshop corner without a special foundation.

Why Choose This Hydraulic Sawdust Briquette Machine?

• Low operating cost. With 13.25 kW total power and no heating element, electricity cost per ton of briquettes is significantly lower than screw machines.
• Simple maintenance. The hydraulic system uses standard industrial seals and valves. Local hydraulic shops can service the machine. No need to import expensive wear screws.
• Safe operation. No high-speed rotating parts. The hydraulic press stops immediately when the emergency button is pressed.
• Flexible production. The 60/70 mm dual mold design lets you serve different markets. Produce 60 mm briquettes for household stoves and 70 mm for industrial boilers.
• Proven durability. The heavy 800 kg frame absorbs vibration and maintains alignment. The hydraulic cylinder is rated for over 500,000 press cycles.

자주 묻는 질문

Get a Quote for Your Hydraulic Sawdust Briquette Machine

The SL-60 hydraulic sawdust briquette machine offers the simplest path to biomass fuel production. With 80 kg/h output, dual mold flexibility, and low power consumption, it pays back quickly for small and medium producers.

Contact Shuliy today. Send us your sawdust type, moisture content, and daily target. We will recommend the right mold size and provide a detailed quotation with shipping options.

Shuliy를 선택하는 이유?

• Custom mold configuration. Shuliy supplies both 60 mm and 70 mm molds with every SL-60 machine. We also customize mold diameter and briquette length for your specific burner or boiler requirements.
• Full raw material testing. Before shipping, we test your actual sawdust sample in our factory. We verify moisture tolerance, briquette density, and output rate. You receive a test video before paying the balance.
• Simple maintenance design. The hydraulic system uses standard industrial seals and valves available in most local markets. No need to import expensive wear screws or heating rings. Annual maintenance cost stays under 5% of machine price.
• Proven export experience. Shuliy has shipped sawdust briquette machines to over 60 countries. We handle voltage customization (220V/380V/440V), export packaging, and customs documentation for your region.
• Fast spare parts supply. We stock molds, hydraulic seals, and oil filters for immediate shipment. Spare parts dispatch within 48 hours of order confirmation.
• 12-month warranty with lifetime support. All mechanical and hydraulic components carry a 12-month warranty. Our engineers provide remote troubleshooting within 24 hours and on-site service when needed.
